Saxon Conventional Lathe
Contact f/price
Reason for Reporting
Model C6266A1 x 3000
Specifications
Basic Specifications
Make & model Saxon C6266A1
Distance between centers: 2000 mm
Swing over bed: Ø 660 mm
Spindle bore: Ø 105mm
Spindle head joining style: D1-8
Spindle-reducing bush taper: Ø 113 mm (1:20)/ MT5
Spindle speed grade: 25 – 1600 rpm
Travel of tailstock sleeve: 235 mm
Diameter of tailstock sleeve: Ø 90 mm
Inside taper of tailstock sleeve : MT5
Power of the main motor: 7.5 kW (10PH)
Power of the cooling pump: 0.09 kW (1/8HP)
Machine dimensions (L x W x H)3660 x 1200 x 1600 mm
Machine weight 3590 kg
